Xbox 360 Model Check

“Xbox 360 Controller Emulator” allows your controller (gamepad, joystick, steering wheel, pedals, etc.) to function as an Xbox 360 controller. It allows you to remap buttons and axes and to drive cars with Steering Wheel and Pedals or to fly planes with Joystick and Throttle in games like “Grand Theft Auto”, “Mafia” or “Saints Row”. Changing the Region of Xbox 360 Game. Once the Xbox 360 is modified, you can either change the region of the game or turn your Xbox region free. The video below explains how to change the region of the game by uploading it your computer and burning it in the necessary region using the free 360 Flash Dump Tool.

Howto find the numbers

Video mode
If you live in Europe you usually have a PAL system, North-American it's usually NTSC, Japan is NTSC, rest of Asia is usually PAL. Take a look at this Wikipedia image to get a better understanding of your video mode.
Manufacturer date
You find this date on the backside of the Xbox 360 unit, it's right between the video and power cables.
picture by Anandtech
LOT number
The lot number is printed on the paper box, on the left side seen from the front. Use the picture below to find the exact number.
Team number
This number is also located on the same printed label as the lot number. Use the picture below to find your team number.
DVD Drive
There are currently two different DVD-ROM drives available for the Xbox 360; the first is a Hitachi-LG drive and the other is a Toshiba-Samsung drive. It's the latter one that is currently the most sought after drive.
In 2007, a new BenQ drive was also introduced in the Elite and later Premium and Arcade packages.
You can open the tray and look where the holes are to determine the DVD drive you own.
picture by llamma.com and gmodz.ca
Firmware
Every drive has a firmware printed on top of the drive, this requires you to open the console and look at the topside of the DVD-ROM drive.
picture by llamma.com
HDMI
The new Xbox 360 machines manufactured after July 2007 will most likely include the new HDMI connector. The pack will be marked to say it includes HDMI and on the site it will say codename Zephyr.
picture by shacknews.com
Fan model
The fan model can indicate how much fan noise the machine will generate when the temperature raises and fans begin to rev-up.
The easiest way to find the fan model is to look through the ventilation holes on the back of the machine, or if possible, open the machine up and remove the fan from the case. The delta and Sunon fans are known to generate noise, while the Nidec fans are somewhat quieter.

  • Delta - Black and white/silver label
  • Sunons - Green and white label
  • Nidec - All back label

Checklist

There are currently two different DVD-ROM drives available for the Xbox 360; the first is a Hitachi-LG drive and the other is a Toshiba-Samsung drive. It's the latter one that is currently the most sought after drive. In 2007, a new BenQ drive was also introduced in the Elite and later Premium and Arcade packages. Turn the console on. It'll either say xbox, xbox 360 or xbox one when launched.come on Rare release a good banjo game. You know you want to:) User Info: goofoff06. Goofoff06 (Topic Creator) 2 years ago #4. For real I didn't know never had a xbox before. Took me a few minutes to get a camera and pic.

picture by totallyrocks at ps3forums.com
Motherboard model
Microsoft regularly makes new revisions of the motherboard to fix faults, make it more efficient, and lower the manufacture costs. There are, as of August 2008, four revisions, each has its own codename. Look at the pictures below to determine your board revision. See the full details here.
The power connector on the back of the console can reveal which motherboard you have by comparing the details shown in the picture below.
Xenon (launch 2005)
  • Launch model
  • Red Ring of Death / heat issues
  • 203 Watt powersupply / 12V rated 16.5A

picture by llamma.com
Zephyr (early 2008)Xbox 360 model check
  • HDMI output
  • Extended GPU cooler
  • 203 Watt powersupply / 12V rated 16.5A

picture by llamma.com
Falcon (late 2007)

Xbox 360 Model Checking


  • 65 nm CPU
  • Bigger CPU cooler
  • 175 Watt powersupply / 12V rated 14.2A

picture by llamma.com
Opus (mid 2008)

Xbox 360 Model Check

  • No HDMI output
  • Replacements for Xenon repairs, 65 nm CPU
  • 175 Watt powersupply / 12V rated 14.2A

picture by xbox-underground.netCheck
Jasper (late 2008)Xbox 360 Model Check
  • 65 nm GPU (the true way to idenfify a Jasper is by looking at the chip)
  • 256 MB internal flash memory
  • 150 Watt powersupply / 12V rated 12.1A
  • Limited Edition: Modern Warfare model with 250 GB hard drive

pictures by xbox-scene.com
Jasper Kronos (late 2009)
  • Kronos1 65 nm GPU

Velje (mid 2010)
  • Xbox 360 Slim
  • Smaller casing and new motherboard
  • 45 nm GPU/CPU combined chip
  • 133 Watt powersupply / 12V rated 11.1A

There might be other motherboard configuration, i.e. 16.5A printed on the case of a Jasper motherboard or a Xenon motherboard with a Zephyr GPU cooler. The sets of details above can be used to idenfity the 5 major configurations that is manufacturered in large quantities.Model

Xbox 360 Model Checker

This Check is for the New Black Xbox Slim Console Only Not The Phat Model

With the Slim Xbox 360 console there are some models as at April 2012 that cannot be modded work however is underway to overcome this hurdle and a fix will be available soon


Before contacting us Its Important to check the 12V current consumption information at the back of the Slim console directly above the AV plug you will find this listed 12V - DC symbol - then the DC current figure

If your 360 Slim console is the Same as Above, Says 10.83A Your 100% OK for the Reset Glitch Mod
You may be OK for DVD drive iXtreme firmware Mod or Xk3y (if your internal drive is a Liteon DG16D4S)

If your console says 9.86A it is likely to have a 16D5S Liteon DVD drive and the HANA chip missing
Your out of luck at the moment however keep an eye out on the main page of the website for the latest info
There have been instances in the past that a console with a current consumption of 9.86A have a drive that can be modded and motherboard with the hana chip this however is extremely rare.

Not 100% but another way to check what type of DVD drive you have is via the serial number of your Xbox console
This method is not a100% Guarantee though see note
This Mothod of Checking the ID via serial is not a full proof way


Check the 4th number from the right of Serial Number in this case as above serial ID is 3
XXXXXXXX3XXX : Serial Number
2 - Liteon 9502 DVD drive OK to Firmware Mod or X3key
3 - 0225 Liteon DVD drive OK to firmware mod or X3key
4 or 0 - Possible Hitachi 0500 No firmware or X3key at the moment **see note


Note***We have had over the last 2 weeks five consoles with a serial ID of 4 in theory Hitachi 0500 and they all had original 9502 firmware stamped on the drive case These console all original virgin untouched
We dumped the firmware in Jungle flasher, The dumped firmware displayed as version 0225

Xbox 360 Serial Number Model Check

This happens during the system update after 13141 Microsoft change the firmware of 9502 to 0225
This explains why you may buy a new DVD drive stamped 9502 and yet the firmware reads 0225 in Jungle flasher
Its Nothing to do with Dodgy Chinese suppliers doing a shifty The drives have simply been updated

Xbox 360 Serial Number Model Check

Anyway to make things simple and to be 100% certain your slim console can be modded
The Xbox needs to be opened then inspected we do this free at no charge for our time
